| Colour |
| White |
| Mounting |
| Flush |
| Number Of Cannels |
| 1 |
| IP Rating |
| IP40 |
| PIR Detection Range |
| 7 Metres Diameter Maximum |
| PIR Detection Angle |
| 360 Degree |
| Maximum Fluorescent Light Load |
| 500 Watt |
| Maximum Low Energy Light Load |
| 500 Watt |
| Maximum Filament Light Load |
| 2000 Watt |
| Maximum Halogen Light Load |
| 1000 Watt |
| Height mm |
| 52mm |
| Width mm |
| 80mm |
| Depth mm |
| 80mm |
| Light On Adjustable Time |
| 5 Seconds To 20 Minutes |
| Light On Adjustable Time |
| 5 Seconds To 60 Minutes with IR10 Remote Control |
| Permanent On Facility |
| Electronic with IR10 Controller |
| Information |
| Adjustable Light Level Control |
| Information |
| Optional infra-red remote control for remote set-up and adjustment using part code IR10. Also gives extended lamp ON times |
| Information |
| LED indication on detection and on optional remote control set-up |
| Information |
| Side or bottom cable entry |
| Conforms To Directives |
| 73/23/EEC & 89/336/EEC |
| Operating Voltage |
| 230 Volt AC |
